Start 110 copper at 350 SFM with a carbide turning insert: about 1,337 RPM on 1 inch stock. Rough at 0.0100 in/rev and about 0.05 inch depth of cut, finish at 0.004 in/rev and 0.005 inch.
What RPM and feed for 110 copper?
| Work diameter | Ideal RPM | RPM on a 2500 RPM mini lathe |
|---|---|---|
| 0.25" | 5,348 | 2,500 |
| 0.5" | 2,674 | 2,500 |
| 0.75" | 1,783 | 1,783 |
| 1" | 1,337 | 1,337 |
| 1.5" | 891 | 891 |
| 2" | 668 | 668 |
| 3" | 446 | 446 |
| 4" | 334 | 334 |
Feed: roughing about 0.0100 in/rev at 0.05 inch depth of cut; finishing about 0.004 in/rev at 0.005 inch. On a 7x mini lathe the power feed rates are fixed by the change gears, so pick the nearest.
Tools for cutting 110 copper
How does 110 copper machine?
Pure copper is soft and gummy, which is harder to machine well than its softness suggests. Very sharp, high positive rake tools, a generous flow of cutting fluid and a light finishing pass are what get a clean surface.
Why a carbide turning insert?
Carbide inserts need surface speed and a real depth of cut to work as designed. On a mini lathe, choose sharp, positive, ground inserts (CCGT or DCGT style for non-ferrous, CCMT for steel) rather than the heavy-chipbreaker inserts built for industrial machines.
Adjust speeds with the RPM calculator and milling feeds with the feed rate calculator. The cutting speed chart compares every material.
Frequently asked questions
What SFM for 110 copper?
A starting surface speed of 100 SFM with HSS and 350 SFM with carbide, and 90 SFM for HSS drills. These are conservative for hobby machines; raise them in steps if the chips come off clean and the tool stays cool. 110 copper rates poor (gummy) for machinability.
What happens if my machine cannot reach the RPM?
Run at your top speed. Running below the ideal surface speed only makes the job slower; it does not damage the tool. For milling and drilling, keep the chip load per tooth or feed per revolution the same so the edge keeps cutting instead of rubbing, which lowers the feed in inches per minute in proportion.
